Description
Electric and Gas
Capacity: 20 x 1/1 GN
Number of meals per day: 150-300 meals
Lengthwise loading: 1/1, 1/2, 2/3, 1/3, 2/8 GN
Width: 879 mm
Depth: 791 mm
Height: 1,782 mm
Water inlet: R 3/4“
Water outlet: DN 50
Water pressure: 150–600 kPa or 0.15-0.6 Mpa
Electric:
Weight: 259 kg
Connected load: 37 kW
Fuse: 3 x 63 A
Mains connection: 3 NAC 400 V
“Hot air” output: 36 kW
“Steam” output: 36 kW
Gas:
Weight: 284 kg
Height incl. flow guard: 2,087 mm
Electrical connected load: 0.7 kW
Fuse: 1 x 16 A
Mains connection: 1 x 16 A
Gas supply/connection: R 3/4“
Natural gas/liquefied petroleum gas LPG:
Max. nominal heat input: 44 kW/44 kW
“Hot air” output: 44 kW/44 kW
“Steam” output: 38 kW/38 kW
